Rock Wool Production Line with 1200-2400mm Length and Class A1 Fire Resistance Including Overseas Engineer Support

Rock Wool Production Line with 1200-2400mm Length and Class A1 Fire Resistance Including Overseas Engineer Support

Nombre De La Marca:	Greenson
Cuota De Producción:	1
Precio:	US $2000000-4000000
Condiciones De Pago:	L/C, T/T

Información detallada

Descripción del producto

Información detallada

Lugar de origen:

Hebei

Nombre del producto:

Fabricado en China Línea de producción de paneles de lana de roca Fábrica de máquinas para fabricar

Palabra clave:

Planta de línea de producción de tableros de lana de roca

Capacidad de producción:

10000-50000 toneladas/año

Densidad:

100 a 200 kg/m3

Proceso principal:

mezclado, moldeado, corte de agua, secado

Resistencia al fuego:

Clase A1

Longitud:

1200-2400m m

Servicio postventa:

Ingenieros disponibles para maquinaria de servicio en el extranjero

Resaltar:

1200-2400mm Length Rock Wool Production Line

Class A1 Fire Resistance Mineral Wool Board Production Line

Overseas Engineer Support Rock Wool Panel Production Line

Descripción del producto

Made In China Rock Wool Panel Production Line Mineral Wool Making Machine Factory

The raw materials used in rock wool production include basalt, dolomite, binders, etc. The raw materials are loaded into the hopper by the elevator, and the melting furnace is heated and melted into the melt flow tank. The lava flow is cooled and spun into fibers by the centrifuge, and then sprayed into the fiber molding room. The binder is added during the spraying process, and the fibers are heated by the negative pressure wind. Pull down to the mesh belt to form the original felt. The mesh belt transports the original felt to the pendulum cloth machine to swing the cloth. The original felt after the swing cloth is transported to the curing furnace by the cloth machine, and runs forward between the upper and lower chain belts. The hot air blower blows the hot air into the curing furnace. The cotton felt in the furnace is solidified, and the solidified products are cut, first longitudinally cutting, and then transversely cutting, and the finished product is packaged and put into storage.

Product Parameters

Specification	Details
Application	Manufacture Rock Wool Blanket, Rock Wool Board
Capacity	10000tons/year, 20000tons/year, 30000tons/year, 40000tons/year, 50000tons/year, 60000tons/year, 70000tons/year, 80000tons/year
Raw materials	Basalt, dolomite, binders and so on
Main energy supply system	Raw coal energy supply system Power energy supply system Natural gas energy supply system

Frequently Asked Questions

Q: Where is the factory located?

A: We are located in Shijiazhuang, Hebei Province.

Q: What is your delivery time?

A: Usually, we make merchandise inventory. If we have the products in stock, the delivery time is 30-60 days after receiving the deposit. If we don't have the products in stock, we will arrange the production immediately, with delivery time of 1-3 months depending on order quantity.

Q: How can we ensure quality?

A: The final inspection is always carried out before shipment.

Q: How to install the equipment after purchasing?

A: Professional designing, manufacturing, installation and commissioning team. On-site installation and commission until the production of qualified products.

Q: Do you offer a guarantee?

A: Yes, we guarantee our product for one year. Provide after-sales service support with technical support.
